Drum Dispensing Systems
Dispense DEF from standard 55 gallon drums. KleerBlue offers a wide range of systems at various flow rates.
Image is not available
Image is not available
Slider

Avoid DEF contamination by using a closed system dispensing solution. KleerBlue offers several options including a bracket-mounted electric, direct-mounted electric, and high volume hand dispensers. Each electric option is available with or without a meter and with a 12 or 110-volt motor.

ELECTRIC PUMP OPTION
  • 8 GPM capability
  • Self-priming membrane pump,
  • 12 or 110-volt motor
  • Energy-saving built-in timer
  • Optional meter
  • 20' Delivery hose
  • Stainless steel automatic shut-off nozzle with swivel end
  • Suction hose
  • Drum top-mounted bracket
  • Stainless steel Micro Matic RSV dispense coupler for a quick connection and drybreak release

ROTARY HAND PUMP OPTION
  • 1 gallon per 10 revolutions
  • 12' of 3/4" hose
  • RSV compatible coupler
  • Polyethylene ball valve with spout
  • Optional meter

PISTON HAND PUMP OPTION
  • 1 gallon per 11 down-strokes
  • RSV compatible coupler
  • Hose
  • Dispense valve




Dispense DEF from 55 gallon drums where a closed system isn't required with these affordable dispensers. KleerBlue offers several options including a top-mounted electric, air-driven, and gravity dispenser.

AIR-DRIVEN OPTION
  • 6.5 GPM
  • Air-operated poly polypropylene constructed pump
  • Maximum of 100 psi operating pressure
  • Bung adapter
  • Suction tube to fasten the pump to a drum
  • 12' hose kit with poly trigger nozzle

HIGH VOLUME HAND PUMP OPTION
  • 1 gallon per 10 revolutions
  • Rotary high volume hand pump
  • 12' of 3/4" hose
  • Polyethylene ball valve with spout
  • Optional meter

MANUAL OPTION
  • 1 gallon per 11 strokes
  • Light duty polypropylene piston hand pump
  • Optional hose
  • Optional dispense valve
  • Will attach to a 2" FNPT

GRAVITY OPTION
  • Fittings
  • Vent
  • 9' hose
  • Manual nozzle
