2000/2600/7100 Gal Ultra Remote Tank
Large volume, small footprint, & cold weather-ready DEF tanks to supply dispensers. Sleek exterior looks great at any facility!
Image is not available
Slider

Ultra Series Bulk Storage Units:
Large Storage. Small Footprint. Sleek Design.

The first and largest of our Ultra Series bulk tanks, this classy and robust unit is the perfect solution for large fleets and retailers.

Aboveground bulk tanks offer many advantages including lower initial cost and ease of expansion. However, where to locate the tank at your facility can be an issue. KleerBlue’s Ultra Series turn-key unit solves this dilemma. Offering the industry’s largest storage capacity within a compact, heated and insulated, and aesthetically pleasing unit, it is everything you’ve ever wanted in an aboveground bulk tank.

KleerBlue Ultra Series 7100 Gallon Aboveground DEF Bulk Tank

SIZE THAT ELIMINATES TIMING ISSUES

Take control of your bulk delivery schedule and ensure you’re getting the best price for your fluid.

  • 2,000 and 2,600 gallon capacities allow for improved scheduling and pricing.
  • Extra-large 7,100 gallon capacity allows for 5000+ gallon transport deliveries without needing to completely empty the tank.
DESIGN THAT LOOKS GREAT AT YOUR FACILITY

Large bulk storage doesn’t have to be an eyesore.

  • The white weather-proof exterior can be customized to match your overall facility branding and design.
  • The small footprint offers many placement options.
  • Aboveground tank eliminates need to bury an underground storage tank.
QUALITY THAT BRINGS PEACE OF MIND

Made for the most demanding environments.

  • Volume safety margins combined with overfill protection prevents inventory loss.
  • Experience true secondary containment - 2 inner tanks and an outer wall.
  • Weather-proof exterior offers long life and low maintenance.
BUILT FOR ALL WEATHER CONDITIONS
  • Industrial-grade insulation protects against both extreme heat and cold.
  • KleerBlue’s optional immersion heating (7100 tank) provides improved protection  over traditional forced air systems.



DIMENSIONS/SPECIFICATIONS

Standards & Approvals:

  • ISO 22241 - 3 & 4

Operating Temperature:

  • -22˚F/-30˚C to 130˚F/54˚C

Size & Dimensions:

  • Capacity: 7,100 gallon maximum (6,500 gallons + 10% safety factor)
  • Dimensions: 101” width x 216” length x 118” height

Tank and Container:

  • HDPE primary tank and secondary containment
  • High-performance composite galvanized steel external container
  • Galvanized steel floor panels with all-steel sub-floor
  • Top mount and side access doors
  • Inside enclosure light
  • Patent Pending Design

Heating & Insulation:

  • R-10 Insulation
  • Option: Thermostatically controlled KleerBlue immersion heating system
  • Option: Exhaust fan

Electronics:

  • Three 20 amp 115V AC circuits required
  • External digital level display
  • UL-508A pump and dispenser control box
  • Option: Multiple dispenser switch box
  • Option: External junction box

Pump:

  • Submersible pump
  • Option: 1 HP DEF submersible pump
  • Option: Dual or Tri DEF submersible pumps

Security/Accident Prevention:

  • Lockable access door
  • Mechanical overfill protection
  • Pressure relief system
  • Vent with protective screen
  • Option: Audible overfill alarm
  • Option: 1” stainless steel filter for discharge line

Fill Inlets:

  • 2” stainless steel lockable ball valve
  • Option: 2” stainless steel drybreak (Parker, OPW or TODO)

Dispenser Compatibilities:

  • 1” Female NPT stainless steel pump discharge line connection
  • Compatible with KleerBlue and 3rd party dispensers
  • Dispenser switch box for remote dispensing (see electronics)
  • Option: Powder coated transition boxes for 3rd party dispensing options

Installation:

  • Forklift compatible
  • Completely assembled and wired
  • Anchor kit



DIMENSIONS/SPECIFICATIONS

Standards & Approvals:

  • ISO 22241 - 3 & 4

Operating Temperature:

  • -22˚F/-30˚C to 130˚F/54˚C

Size & Dimensions:

  • Capacity: 2,000 or 2,600 Gallons
  • Dimensions: 98” width x 144” length x 122” height

Tank and Container:

  • HDPE primary tank and secondary containment
  • High-performance smooth surface white aluminum composite exterior panels
  • Easy-to-clean FRP interior surfaces
  • Powder-coated steel base frame
  • Top mount and side access doors
  • Inside enclosure light
  • Patent Pending Design

Heating & Insulation:

  • R-10 Insulated top & sides
  • Forced air heating system
  • Option: Exhaust fan

Electronics:

  • Three 20 amp 115V AC circuits required
  • External digital level display
  • UL-508A pump and dispenser control box
  • Option: Multiple dispenser switch box
  • Option: External junction box

Pump:

  • 3/4 HP DEF submersible pump
  • Option: 1 HP DEF submersible pump
  • Option: Dual or Tri DEF submersible pumps

Security/Accident Prevention:

  • Lockable access door
  • Mechanical overfill protection
  • Pressure relief system
  • Vent with protective screen
  • Option: Audible overfill alarm
  • Option: 1” stainless steel filter for discharge line

Fill Inlets:

  • 2” stainless steel lockable ball valve
  • Option: 2” stainless steel drybreak (Parker, OPW or TODO)

Dispenser Compatibilities:

  • 1” Female NPT stainless steel pump discharge line connection
  • Compatible with KleerBlue and 3rd party dispensers
  • Dispenser switch box for remote dispensing (see electronics)
  • Option: Powder coated transition boxes for 3rd party dispensing options

Installation:

  • Forklift compatible
  • Completely assembled and wired
  • Anchor kit
