Begin offering DEF at your facility with minimal interruption. Designed with a small footprint and internal dispensing system, the KleerBlue’s Ultra 500XL and 1000XL turn-key solutiosn can be quickly installed almost anywhere at your facility. They come assembled, pre-wired and pre-plumbed with forklift access points. The sleek, glossy white exteriors are easy to clean and maintain. With no bottom or sidewall outlets, the Ultra 500XL and 1000XL avoid leaks and will continue to look good for years to come!
Small Footprint!
Maximize storage while minimizing fueling-island space requirements.
500 Gallon
- 500 gallons useable capacity (528 gallons brimful capacity) combined with overfill protection prevents inventory loss.
- Enclosure base is only 96” long x 36” wide!
1000 Gallon
- 1000 gallons useable capacity (900 gallons brimful capacity) combined with overfill protection prevents inventory loss.
- Enclosure base is only 144” long x 46” wide!
An Internal Dispenser Configured to Your Needs
- KleerBlue Summit Commercial Dispenser Components
- Island or Lane Oriented Dispenser
- Single or Dual Dispenser
- Spring Rewind Hose Reel with 25’ of Hose
Quick, Cost-Effective Installation
- Turn-Key enclosure is assembled, pre-wired, pre-plumbed and tested.
- The powder-coated steel base frame includes forklift access points for easy handling.
Design that Looks Great at Your Facility
Above ground DEF storage doesn't have to be an eyesore.
- The white weather-proof exterior can be customized to match your overall facility branding and design.
- Exterior is smooth and glossy for easy-to-clean, long-term maintenance.
Cold Weather Ready
- Insulation protects DEF against both extreme heat and cold.
- Efficient heating system ensures you can pump DEF even in cold temperatures.
Standards & Approvals
- ISO 22241-3&4
- PEI RP1100
Size & Dimensions
- Capacity: 500 gallons useable capacity (528 gallons brimful capacity)
- Footprint: 96" wide x 36" long x 101" high
Operating Temperature
- -22˚F/-30˚C to 130˚F/54˚C
- Option: Enhanced heating
Tank and Enclosure
- High-performance composite exterior panels
- HDLPE primary tank
- Powder coated steel base frame
- Top access manways
Heating & Insulation
- Insulation
- Efficient heating system
- Option: Thermostatically controlled heating system
- Option: Exhaust fan
Electrical
- Operates on 240V 50 amp service
- Digital level display
- UL-508A pump and control box
Pump
- DEF submersible pump
Security/Accident Prevention
- Lockable access door
- Mechanical overfill protection
- Pressure relief system
- No bottom or sidewall outlets (leak prevention)
Fill Inlets
- 2” stainless steel drybreak (Parker, OPW or TODO) or camlock coupler (Not included; specify when ordering.)
Dispenser compatibilities
- Compatible with KleerBlue Summit Commercial dispenser components
Installation
- Forklift compatible
- Completely assembled and wired (enclosure system)
- Anchor kit
Standards & Approvals
- ISO 22241-3&4
- PEI RP1100
Size & Dimensions
- Capacity: 1000 gallon brimful capacity (900 gallons usable)
- Footprint: 46" wide x 144" long x 101" high
Operating Temperature
- -22˚F/-30˚C to 130˚F/54˚C
- Option: Enhanced heading
Tank and Enclosure
- High-performance composite exterior panels
- HDLPE primary tank
- Powder coated steel base frame
- Top access manways
Heating & Insulation
- Insulation
- Efficient heating system
- Option: Enhanced heading to -37˚F/-32˚C
Electrical
- Operates on 240V 50 amp service
- Digital level display
- UL-508A pump and control box
Pump
- DEF submersible pump
Security/Accident Prevention
- Lockable access door
- Mechanical overfill protection
- Pressure relief system
- No bottom or sidewall outlets (leak prevention)
Fill Inlets
- 2” stainless steel drybreak (Parker, OPW or TODO) or camlock coupler (Not included; specify when ordering.)
Dispenser compatibilities
- Compatible with KleerBlue Summit Commercial dispenser components
Installation
- Forklift compatible
- Completely assembled and wired (enclosure system)
- Anchor kit
